Specifications
2
1.2 Specifications
9 (EDSR900) / 16 (EDSR1600) camera inputs (BNC),1Vp-p/75ohm
430mm (W) x 88mm (H) x 300 (D)
Dimension
AC100~240V Power Source
40W max. Power Consumption
Video Input
M-JPEG Video Compression
0 C ~ 40 C Environ. Temperature
2 x RJ45 Socket RS485
9-pin female D-Sub RS-232
Yes Watch Dog Timer
Built-in real time clock Timer
Front Panel Keypad User Input Device
Menu Driven User Interface
On screen display setup (OSD) Setup
By Date/Time, Event, Segment Playback Search
Up to 60/50 fields per second for NTSC/PAL Playback Rate
Up to 60/50 fields per second for NTSC/PAL Recording Rate
Continuous, Timer Schedule, Alarm- or Motion Recording Recording Mode
Two 3.5” IDE type, hot- swappable Hard Disk Storage
Yes Event Log
10BaseT Ethernet, RJ45 connector Ethernet
Yes Video Loss Detection
EDSR-900: Full, 4, 6, 7, 8, 9, PIP and 2x zoom for Live and Playback
EDSR-1600: Full, 4, 6, 7, 9, 10, 13, 16, PIP and 2x zoom for Live and
Playback
Video Display modes
1 alarm output Alarm Output
9 (EDSR900) / 16 (EDSR1600) alarm inputs, 25 pin Sub-D Alarm Input
built-in Compact Flash card slot Compact Flash Memory
720x484 (NTSC); 720x576 (PAL) Recording Resolution
1 BNC video out (1Vp-p/75 ohm) for Main Monitor
1 S-Video out Mini DIN for Main Monitor
5 BNC video out (1Vp-p/75 ohm) for Matrix / CALL Monitor output
9 (EDSR900) / 16 (EDSR1600) video out (1Vp-p/ 75 Ohm)for looping
Video Output
NTSC/PAL Video Format
Audio 2 x Audio In / Out Cinch 500mV max., 10K Ohm impedance
