System Connection
5
3. System Connection
The installations described below should be made by qualified service personnel or system installers.
Before Installation
Please refer to the following diagram for the system connections.
Matrix Outputs
4 CALL Monitors
(Optional)
EDSR 900: Camera 1~9 / EDSR-1600: Camera 1 ~ 16
~
CALL Monitor
Audio Input
(camera Audio Out) Audio Out
(To Speaker)
MAIN Monitor
Ethernet RS232
Alarm In/Out
RS485
Remote Keyboard(s)
KS-KBJ / KS-KBK
(optional)
or
Speed dome / telemetry receiver
