42 GB
Start-up / Operation
Using the router tool
Press and hold the spindle lock key 10 .
Release the union nut 3 with the open-ended
spanner 27 by turning it anticlockwise.
Release the spindle-lock key 10 .
Then use the router tool. This must be inserted
at least 20 mm (shaft length).
Tighten the union nut 3 firmly with the open-
ended spanner 27 .
Attaching the extractor adapter
Put the extractor adapter 21 on the drilling ex-
tractor 18 provided.
Screw together the extractor’s screws 22 and
the under side of the base plate 7 .
Connect a vacuum device approved for the
extraction of sawdust and splinters to the ex-
tractor
21 (see Fig. G).
Reducer
Connecting:
Slide the reducer 28 in to the suction adapter 21 .
Slide the hose for an approved dust extraction
unit (e.g. a workshop vacuum) onto the reduc-
er
28 .
Removal:
Pull the hose of the vacuum unit off of the re-
ducer
28 .
Pull off the reducer 28 .
Changing the collet
Note: All router bits of the router sets have a 8 mm
shaft.
Start with the already installed collet 8 mm
4 .
Change the collet for a router bit with a 6 mm shaft
as described below.
Release the union nut by turning it anticlockwise
using the open-ended spanner
27 until the collet
8 mm 4 is removed.
Insert the collet 6 mm 23 .
ATTENTION! Tighten the union nut 3 firmly
with the open-ended spanner 27 once the rout-
er bit 17 is inserted. Otherwise the collet might
be damaged.
Fitting the guide fence
Unscrew the both of the sliding bar’s 29
screws with a Philips screw driver.
Secure the sliding bar 29 to the rip fence 24 and
tighten the screws.
Operation
Switching on and off
Switching on:
Press and hold the start lockout 20 .
Activate the ON / OFF switch 19 . Once the
machine has started, release the start lockout 20 .
Switching off:
Release the ON / OFF switch 19 .
Presetting the speed
Set the desired speed using the speed setting
wheel
1 .
1–2 = low speed
3–4 = middle speed
5–7 = high speed
Set the milling depth
1. Ensure that the clamping lever 16 is locked down.
If it is loose turn it anti-clockwise until it is locked.
2. Place the device on the work piece to be worked
upon.
3. Turn the step stop 9 until it locks into the lowest
position.
4. Loosen the lock screw 11 .
Operation
