38 GB
Introduction
Router POF 1200 A1
Introduction
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the unit as described
and for the specified applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Intended use
This device is intended to mill grooves, edges, pro-
files and slots on a wooden, plastic or light surface,
as well as copy milling. This device is not intended
for outdoor use. Any other uses, and / or modifica-
tions to the appliance, are deemed to be improper
usage and may result in serious physical injury. Not
for commercial applications.
Features
Front view figure A
1 Speed setting
2 Handle
3 Union nut
4 Collet 8 mm (preinstalled in union nut 3 )
5 Locking screw
6 Guide rail
7 Base plate
8 Sliding plate
9 Step stop
10 Spindle-lock key
11 Lock screw
12 Depth stop
13 Index indicator
14 Dial milling depth adjustment
15 Control dial (milling depth-fine adjustment)
Back view figure B
16 Clamping lever
17 Router tool
18 Drilling extractor adapter
19 ON / OFF switch
20 Start lockout
Parts figure C
21 Extractor
22 Screw
23 Collet 6 mm
24 Rip fence
25 Thrust ring
26 Copy casing
27 Open-ended spanner with slot
28 Reducer
29 Sliding bar with screw for rip fence 24
30 Centring pin
31 Socket head wrench
Router set figure E
32 Round and profile cutter ∅ 22 mm / R 6.3 mm
33 Round and profile cutter ∅ 28.6 mm / R 9.5 mm
34 Round and profile cutter ∅ 25 mm / R 4 mm
35 Hollow cutter ∅ 12.7 mm / R 6.3 mm
36 Hollow cutter ∅ 22 mm / R 6.3 mm
37 V-groove cutter ∅ 12.7 mm / Angle 90°
38 Bevel cutter ∅ 32 mm / Angle 45°
39 Flush cutter ∅ 12.7 mm
40 Dovetail cutter ∅ 12.7 mm / Angle 14°
41 Slot cutter ∅ 6 mm
42 Slot cutter ∅ 12 mm
43 Slot cutter ∅ 16 mm
Scope of delivery
1 Router
1 Open-ended spanner with slot
1 Collet 6 mm
1 Collet 8 mm (installed)
1 Extractor
1 Rip fence with 2 guides
1 Copy casing with 2 screws
1 Centring pin
1 Milling set 12 parts
1 Reducer
Introduction / General power tool safety warnings
