8
Downdraught Extractor
The air is sucked in at the air
dampers through the fat filter and is
then blown via the extraction hose to
the extraction duct and out into the
open air.
Height positions
The downdraught extractor has 4
different extraction strengths:
150m3/h, 220m3/h, 345 m3/h and
480 m3/h.
When installed beside a gas
appliance, the down-
draught extractor can only
extract in the top position.
Extraction rates
When installed beside electrical
appliances, the downdraught extrac-
tor can be adjusted continuously
from the centre position to the top
position.
The downdraught extractor has an
electronic control system.
The electronics have the following
functions:
-
Extraction rate display
- Timer-controlled operation
- Autostop
- Grease filter cleaning indicator
Electronic control system
