25
3. Fitting the cover plate
Fit the cover plate as follows:
1. Position the cover plate against the glass on the top cabinet.
2. Position the cover plate against the top cabinet.
3. Mark the four holes on the top cabinet, using the cover plate as a template.
4. Remove the cover plate and drill the four marked holes with a 3.2mm drill.
5. Take the backing off the tape.
6. Lay the cover plate against the top cabinet and press firmly into place.
7. Fix the plate through the four holes with the supplied blind rivets.
The downdraught extractor must not be used beside a gas unit if air
recirculation is chosen for the kitchen.
