5
GB
General description
The illustration of the principal
functioning parts can be found
on the front and back foldout
pages.
Delivery Contents
Unpack the equipment and check that it is
complete.
The equipment is supplied with the motor
head on (see 3).
To take off the motor head and remove the
accessories, release the locking lever (
16) and fold down the bow handle
tie bars ( 2) towards the suction nozzle
( 8).
- Motor housing
- Stainless steel container
- Bow handle
- Cable holder
- Front steering castor
- 4 attachment ports with rear steering
castor
- 2 wheels with hubcaps
- Telescopic suction pipe
- Suction hose
- Handle with air regulation
- Foam filter
- Fluted filter + filter cover (already
mounted)
- Paper filter bag
- Switchable household nozzle
- Crevice nozzle
- 10 cross-head screws
- 2 plastic washers
Dispose of the packaging material in a
proper manner.
Overview
Housing
1 Bow handle
2 Bow handle tie bars
3 Motor housing
4 Cable holder
5 Mains power cable
6 On/off switch
7 Vent holes
8 Suction connection
9 Stainless steel container
10 Drainage outlet
11 Front steering castor
12 2 wheels with hubcaps
13 Anti-static chain (not visible)
14 Rear steering castor
15 4 attachment ports for acces-
sories
16 Locking lever
17 Blow connection
18 2 attachment ports
19 Telescopic suction pipe
. Accessories
20 Vacuum tube holder
21 Suction hose
22 Handle with air regulation
Filter
23 Foam filter for wet vacuuming
24 Filter cover
. 25 Fluted filter for dry vacuuming
26 Paper filter bag for fine dust
. Nozzles
27 Switchable household nozzle
for vacuuming carpets
for vacuuming smooth surfaces
28 Crevice nozzle
Description of operation
The equipment is fitted with a stable
stainless steel container to hold liquid
and dust. The wheels and swivel castors
give the equipment great mobility. For
