L, M, H) is prohibited.The manufacturer
will not be held responsible for injuries
resulting from use which does not comply
with the directions, or from incorrect use.
General description
Description of operation
The ash vacuum cleaner is fitted with a
stable metal container with a cover. The
vacuum set comprises a flexible metal
suction hose and an aluminium suction
hose. A safety stop prevents the equip-
ment from being usable without a filter.
The following describes the function of the
operating parts.
See the front fold-out page for
illustrations.
Overview
1 M ains cable
2 Accessory holder
3 Inspection window blockage
indicator
4 Retaining bracket
5 Container lid
6 On/off switch
7 Hose connection
8 Seal clips
9 Carry handle
10 Metal container
11 Metal suction hose
12 Suction tube
13 Pleated filter
14 Wire filter basket
15 Safety stop
16 Metal lugs
17 Air filter
18 Filter housing
Delivery Contents
Unpack the equipment and check that it is
complete.
5 Container lid
10 Metal container
11 Metal suction hose
12 Suction tube
13 Pleated filter (already mounted)
14 Wire filter basket (already
mounted)
Dispose of the packaging material in a
proper manner.
Assembly
Disconnect at the plug before car-
rying out any work on the equip-
ment.
Risk of electric shock!
1. Check that the pleated filter
( 13) and wire filter basket
( 14) are sitting correctly and
securely.
2. Place the container lid (5) on
the metal container (10) and
close it using the seal clips (8).
3. Connect the suction hose (11).
To do this, insert the rotatable
plastic end piece (with the
printed symbol) into the
hose connection (7) and
screw it tight (bayonet con-
nection).
When assembling/detaching the
suction hose, hold the black plastic
end piece and not the metal suction
hose. Twisting or bending could da-
mage the hose.
