B4400/4500/4600 User’s Guide
10
Printer components
Apart from the Operator panels, which are described in the
next chapter, the B4400, B4500, and B4600 printers look
similar from the outside. The important components are
identified in the representations below.
1. Operator panel (B4500 and B4600 shown)
2. Top paper exit bin (150 sheets, face down)
3. Top cover release button
4. Top paper exit bin extension
5. Top paper exit bin extension paper guide
6. Paper tray content indicator
7. ON/OFF switch
8. Rear paper exit tray (50 sheets, face up)
9. Rear paper exit tray paper guide
10. LED array
11. Image drum
12. Manual feed tray (single sheet) (shown in closed
position)
1
2
3
4
5
6
7
8
9
