Cables and Connectors
When using signals with a scanning frequency of 15–125 kHz and running distances of 100
feet or more, use high resolution BNC cables to achieve maximum performance.
Pre-cut Cables
VGA-A M-M MD with audio cable Part number
Lengths from 3' to 50' 26-490-xx
VGA M to BNC M MHR cable, SYM BNCM Series Part number
Lengths from 6" to 100' 26-533-xx
S-video M-M cable, MHR-2 SVM-M Part number
Lengths from 6" to 100' 26-316-xx
Single Link DVI-D Male to Male Cables, DVID
SL Pro Series
Part number
Lengths from 3' to 200' 26-649-xx
High Speed and Standard Speed HDMI Cables,
HDMI Pro Series
Part number
Lengths from 3' to 200' 26-650-xx
Standard Speed HDMI to DVI-D Cables Part number
HDMI DVI-D/xx lengths from 3' to 50' 26-614-xx
Mini-Audio cable, 3.5 mm Stereo Male to Male Part number
2', 6', 12', 25' 26-571-01, -02, -06,
-07
Bulk Cable
Bulk cable Part number
MHR-2, 2 Conductor Mini High Resolution S-Video
Cable, 500 feet, non-plenum 22-123-03
MHR-5, Five Conductor MHR - Mini High Resolution,
500 feet 22-020-02
MHR-5StP-2, Five Conductor MHR and two Shielded
twisted Pairs Plenum Cable 22-175-02
M59-3, three Conductor Mini 59 Flex Cable 22-185-02
RG59, Single Conductor RG59 High Resolution 22-145-02
RG6-1, Single Conductor RG6 Super High Resolution 22-098-02
MHRVGA, Mini High Resolution VGA Cable non-plenum 22-024-01
StP22-2, Serial Control/Audio 22-160-03
StP20-2, Serial Control/Audio Cable, non-plenum 22-161-03
