1
Introduction
Network Application Platforms
Chapter 1
Chapter 1:
Introduction
Thank you for choosing the FW-7575. This system
integrates the newest Intel® Xeon E3 1125C Processor
(or Intel® Core i3 Processor 2115C), codenamed Sandy
Bridge Gladden, with the Intel Cave Creek PCH to upscale
the network platform to the next level. It supports up
to 32GB of DDR3 system memory at 1066,1333 or
1600MHz on dual-channel DIMM banks.
The built-in Intel QuickAssist technology on the Cave
Creek chipset provides bulk data encryption/decryption
using AES, 3DES or (A)RC4 algorithms and hash using
MD5, SHA-1/2 and HMAC algorithms and compression.
The chipset will support Intel Virtualization Technology,
too.
The FW-7575 is equipped with advanced I/O capabilities
which incorporates a console port, an RJ-45 management
port, a PCIex8 golden finger connected directly to the
CPU for utmost packet processing performance and one
Serial-ATA port as well as a ComplactFlash slot. The front
panel also features 6 GbE ports.
The system can add additional 8 LAN ports with 1
Ethernet module, providing a total of 14 LAN ports.
Moreover, these LAN modules can be configured with
Lanner Generation2 or Generation3 bypass depending
on the module specification.
Please refer to the chart below for a summary of the
system’s specifications.
System Specification
Form Factor 1U Rackmount
Platform
Processor Options
Intel® Xeon Processor E3-
1125C (FW-7575A/B)
Intel® Core i3 Processor
2115C (FW-7575 C/D)
Chipset Intel® Cave Creek
BIOS EFI BIOS 64Mbit
System
Memory
Technology
DDR3
1066/1333/1600MHz
unbuffered, non-ECC
Max. Capacity 32GB
Socket 4 x 240P DIMM
OS Support Linux kernel 2.6 or above
Storage
HDD Bays
1 x 2.5” (Default) or 1 x
3.5” SATA HDD (Optional)
CompactFlash 1 x Type II CompactFlash
Networking
Ethernet Ports 6 x GbE RJ45
Bypass 2 pairs Generation 3
PHY chip & LAN
chip
i347-ATZ, 82580DB
Ethernet Modules Yes (optional)
Management Port 1 x GbE RJ45
Security Accelera-
tion Cave Creek QuickAssist
Technology
I/O Interface
Reset Button
1 x reset button
Software reset by default
Console 1 x RJ45
USB 2 x USB 2.0
Expansion
PCIe
PCIe*8 Ethernet Module or
Standard PCIe*8 add-on
card
PCI N/A
Cooling
Processor
CPU heatsink with fan
duct
System
3 x cooling fans with smart
fan control
Environmental
Parameters
Temperature,
ambient operating
/ storage
0 ~ 40º C / -20~70º C
Humidity (RH),
ambient operating
/ ambient non-
operating
5~95%, non-condensing
Miscellaneous
LCD Module Yes
Watchdog Yes
Internal RTC with
Li Battery
Yes
