Rear panel features, Chapter 1, Introduction – Lanner FW-7575 User Manual
Page 10
5
Introduction
Network Application Platforms
Chapter 1
Rear Panel Features
R2
R1
R3
FAN4 FAN3 FAN2
AUX Fan CPU Fan CPU Fan
R1 Standard Low Profile and Half Length PCIe Expansion Slot
R2 System Fans
These fans have smart fan feature. These fans have smart fan feature which can be turned on automatically when the
temperature exceed the set threshold.
R3 Power-on Switch
It is a switch to turn on or off the power.
R4 AC Power Socket
The system equips an ATX 180W Power Supply.
R4
