1
Introduction
Chapter 1
Network Application Platforms
Chapter 1:
Introduction
Based on a new generation high-performance VIA VX900
chipset the FW-6436 offers a compact and convenient
system for secured data exchange and media services.
The chipset integrates the high-performance VIA
ChromotionHD 2.0 video processor, offering advanced
filtering and cutting edge post-processing to perform
ultra smooth decoding of MPEG-4, H.264, MPEG-2, and
VC-1.
Furthermore, you can take advantage of the integrated
security engines to the CPU to increase system
performance and throughput when doing the following
secure computations:
Secure Hash Algorithm • –SHA-1 & SHA-256 and AES
Encryption
RSA Public key algorithm
• –the security engine can
accelerate public key generation enabling up to 900
signings of RSA 1024-bit per second.
Random number generation
• –the engine can produce
truly random numbers at a sustained rate of 12 million
per second.
Prevention of worm executing and spreading during
•
system run-time
The system also supports a variety of I/O interfaces
including 4 Gigabit Ethernet, 2 USB and 2 PCI expansion
slots.
Please refer to the chart below for a summary of the
system’s specifications.
System Specification
Form Factor Desktop
Platform
Processor Options
VIA ULV Eden 500
MHz or VIA C7 1.5
GHz
Chipset VIA VX900
BIOS
AMI BIOS
8Mbit SPI Flash ROM
System
Memory
Technology DDR3 800/1066MHz
Max. Capacity 4GB
Socket 1 x 204P SO-DIMM
OS Support
Windows 2000, 2003,
XP, 7. Linux kernel
2.4 and up, OpenBSD,
FreeBSD
Storage
HDD Bays 1 x 2.5”
CompactFlash
1 x Type II Compact-
Flash
Networking
Ethernet Ports 4 x GbE RJ45
Bypass N/A
Controllers
4x Realtek RTL8111E-
GR
Ethernet Modules N/A
Management Port N/A
Security Acceleration N/A
I/O Interface
Reset Button
1 x reset button
Software reset by
default
Console 1 x RJ45
USB 2 x USB 2.0
IPMI via OPMA slot N/A
Expansion
PCIe N/A
PCI
1 x Mini-PCI
2 x PCI slots
Cooling
Processor Passive CPU heatsink
System
1 x cooling fan with
smart fan control
Environmental
Parameters
Temperature, ambient
operating / storage
0 ~ 40º C / -20~70º C
Humidity (RH), ambient
operating / ambient
non-operating
5~90%, non-con-
densing
Miscellaneous
LCD Module N/A
Watchdog Yes
Internal RTC with Li
Battery
Yes
Physical
Dimensions Dimensions (WxHxD) 375 x 50 x 190 mm
Weight
2.2 kg
Power
Type / Watts
12V 5A 60W Power
Adapter
Input
AC 100~240V
@50~60 Hz
Approvals and Compliance
CE emission, FCC
Class A, RoHS
