SPECIFICATIONS
Clutching
*EBS models require no helix/spring adjustment
SPORTSMAN 550 Touring
Lubrication System Pressurized Wet Sump
Transmission Type Automatic PVT (POLARIS Variable Transmission)
In-Line H-L-N-R-P
Front Suspension Dual a-arm, 9" (22.9 cm) travel
Rear Suspension Dual a-arm with Rolled IRS, 10" (25.4 cm) travel
Gear Reduction, Low 5.034:1
Gear Reduction, Reverse 4.508:1
Gear Reduction, High 2.693:1
Drive Ratio, Front 3.818:1
Drive Ratio, Rear 3.7:1
Tire Type/Pressure, Front Maxxis AT 26 x 8 - 14 / 7 psi (48.3 kPa)
Tire Type/Pressure, Rear Maxxis AT 26 x 10 - 14 / 7 psi (48.3 kPa)
Brakes, Front/Rear Single-Control Hydraulic Disc, All-Wheel
Brake, Auxiliary Foot-Activated Hydraulic Disc, Rear Wheel
Brake, Parking Hydraulic lock, all wheel
Headlight 1 Single Beam on Headlight Pod (50 watt)
2 Single Beam on Bumper (50 watt)
Taillight 12v/7 watts
Brake Light 12v/27 watts
Instrumentation Digital/Analog
Altitude Shift
Weight
Drive Clutch
Spring
Driven
Clutch
Spring
Helix*
Meters
(Feet)
0-1800
(0-6000)
23-54G
PN 1322914
Dark Blue
PN 7043803
Red/White
PN 3235088
105-165 BA3
PN 3235092
1800-3700
(6000-12000)
23-51
PN 1322915
Dark Blue
PN 7043803
Red/White
PN 3235088
105-165 BA3
PN 3235092
