MAINTENANCE

Side Panel/Footwell Removal

1. Remove the seat before removing a side panel.

2. To remove a side panel or footwell, remove the fasteners securing it

to the frame. Lift the right side panel upward while removing it to
clear the shifter knob

Plastic Rivet

Hex Head Screw

Plastic Rivet
