108
MAINTENANCE
Seats
Passenger Seat Suspension
1. Remove the passenger seat.
2. Remove the fastener retaining the
passenger seat shock to the passenger
seat support.
3. Pivot the seat support upward to
access the lower shock fastener.
Remove the lower shock fastener.
4. Remove the shock from the vehicle.
If adjustment is necessary, use a
suitable pliers or spanner wrench.
Adjust the shock to the desired
spring preload. Rotate the adjustment
cam to the left to increase preload.
5. Reinstall the shock.
6. Torque the upper and lower shock
fasteners to 38 ft. lbs. (51 Nm).
7. Reinstall the passenger seat.
Operator Seat Removal
1. Remove the passenger
seat. See page 107.
2. Grasp one side of the
operator’s seat near the
rear edge.
3. Pull upward abruptly to
disengage the under-seat
fasteners.
4. Remove the seat.
