REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

INCLUDES ITEM 2

MAIN PIPE FIXTURE KIT

1

P021009380

1

CUSHION

1

V420001081

2

SCREW 5X25

2

90016205025

3

SCREW 5X12

1

90010505012

4

INCLUDES ITEMS 6-9

FAN COVER ASY

1

P021009810

5

CIRCLIP 12

1

90070100012

6

BEARING, BALL - 6001

2

90080796001

7

SNAP RING 28

1

90070200028

8

DRUM, CLUTCH

1

A556000040

9

SCREW 4X16

4

90016304016

10

CLIP

1

V491000180

11

SHOE, CLUTCH

2

A553000010

12

SPRING, CLUTCH

1

V451000400

13

SHAFT, CLUTCH

2

17504656030

14

WAVE WASHER

2

17504956030

15

WASHER

2

17504805530

16

99922204103
