REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

INCLUDES ITEMS 2-22

SHORT BLOCK

1

SB1090

1

CYLINDER

1

A130000761

2

SCREW 5X25

4

90016205025

3

GASKET, CYLINDER

1

1

V100000210

4

INCLUDES ITEMS 6-10

PISTON KIT

1

P021009771

5

RING, PISTON

1

A101000170

6

PIN, PISTON

1

10001335430

7

CIRCLIP, PISTON PIN

2

10001503931

8

SPACER, PISTON PIN

2

10001453630

9

BEARING, NEEDLE

1

10001216131

10

CRANKSHAFT ASY

1

A011000434

11

WOODRUFF KEY

1

10014212330

12

INCLUDES ITEMS 14-19

CRANKCASE KIT

1

P021010801

13

OILSEAL

1

V505000050

14

DOWEL PIN

2

V622000020

15

BEARING, BALL - 6201

2

9403536201

16

GASKET, CRANKCASE

1

1

10024242030

17

OIL SEAL

1

10021242031

18

SCREW 5X28

3

90016205028

19

See Pages "Exhaust"

SHIELD, EXHAUST

1

1

------------------

20

See Pages "Intake"

GASKET, INTAKE

1

1

------------------

21

See Pages "Intake"

GASKET, INTAKE

1

1

------------------

22

Footnotes

1: Also Included In GASKET KIT

99922204103

- 21 -

REVISED 06/14/10

Table of Contents

Part Number Index

SRM-265S Trimmer

Engine, Short Block -- SB1090
