REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
CARBURETOR -- RB-K84
1
A021001200
ROTOR COVER ASY
1
P005001980
1
SCREW, ROTOR COVER ASY
3
12534413931
2
SCREW
1
12534452130
3
SCREW, CABLE ADJUST
1
P005001330
4
SWIVEL
1
P005001240
5
E-RING
1
P005000190
6
SCREW, THROTTLE ADJUST
1
P005000100
7
O-RING
1
P005000280
8
NOT AVAILABLE SEPARATELY
BODY, CARBURETOR
1
------------------
9
PLUG
1
P005001270
10
NEEDLE - HIGH SPEED
1
P005001290
11
PURGE BASE ASY
1
P005001890
12
SCREW, PURGE BASE ASY
1
P005000270
13
BULB, PURGE
1
12538108660
14
RETAINER, PURGE BULB
1
P005000250
15
SCREW, PURGE PUMP RETAINER
4
P005001900
16
COVER, DIAPHRAGM
1
12534252130
17
SCREW, DIAPHRAGM COVER
2
12534452130
18
SCREW, METERING LEVER PIN
1
12533942030
19
INCLUDES ITEMS 21-30
REPAIR KIT
1
P005001990
20
ROLLER, GUIDE
1
P005001000
21
PIN, METERING LEVER
1
------------------
22
VALVE, INLET NEEDLE
1
------------------
23
LEVER, METERING
1
------------------
24
SPRING, METERING LEVER
1
------------------
25
STRAINER
1
------------------
26
DIAPHRAGM, PUMP
1
------------------
27
GASKET, PUMP
1
------------------
28
GASKET, METERING
1
------------------
29
DIAPHRAGM, METERING
1
------------------
30
INCLUDES ITEMS 32-35
DIAPHRAGM/GASKET KIT
1
P005001660
31
DIAPHRAGM, PUMP
1
------------------
32
GASKET, PUMP
1
------------------
33
GASKET, METERING
1
------------------
34
DIAPHRAGM, METERING
1
------------------
35
99922204103
- 15 -
REVISED 06/14/10
SRM-265S Trimmer
Carburetor -- RB-K84
