Re-Hanging Door
15
0 Carefully set door into upper
pivot pin and close.
0 Place washer between door and
door pivot at bottom left, and
turn pivot pin (A) into lower
door pivot at the left.
0 Reposition door handle and hole
plug-pins as shown in the dia-
gram.
0 Replace base cover.
2. Appliances without base cover
0 Lay the left side of the appliance
onto a soft pad, e.g. rug, blanket
etc.
0 Turn pivot pin (A) out of lower
door pivot.
0 Romove door carefully and set
aside.
0 Turn the 4 phillips head screws
(B) out of the base and remove
the base.
0 Reposition door pivot (C) as well
as base dummy-pivot (D) as
shown in the diagram.
