10 LDK 4488, LDK 4489 SuperXpander, Xpander User’s Guide (v5.0)
Installation notices
For proper installation the following NEC articles should be noticed:
– Installation of equipment (NEC article 800.18);
– Avoid contact with conductors of other systems (NEC article 810.13);
– Provide extensive, separate clearance requirements for indoor and outdoor locations
(NEC article 810.18).
Tripod installation
The typical configuration for this device (SuperXpander with Triax cables and 7-inch viewfinder
mounted) has proved to be stable when used on a tripod with the following specifications:
weight 24 kg, height 120 cm, leg distance (at floor level) of 135 cm.
Note that these values are recommendations only. Always check the mechanical stability of
the device before using it.
Mains power supply chord
A mains power supply chord is not shipped with the device. To connect the device to the
mains the following power supply cord is advised: type H03 VV-F or H03 VVH2-F flexible wire:
1 mm², 250V / 10A minimum or 16 AWG.
When the device is installed in one of the following countries the power chord must be
compliant to the indicated specifications and regulations below.
Denmark
Supply cord of single-phase equipment having a rated current not exceeding 10A shall be
provided with a plug according to the Heavy Current Regulations section 107-2-D1. Class I
equipment provided with socket-outlets with earth contact or which are intended to be used in
locations where protection against indirect contact is required according to the wiring rules
shall be provided with a plug in accordance with standard sheet DK 2-1a or DK 2-5a.
Ireland
Apparatus which is fitted with a flexible cable or cord and is designed to be connected to a
mains socket conforming to I.S. 411 by means of that flexible cable or cord and plug, shall be
fitted with a 13A plug in accordance with Statutory Instrument 525:1997 - National Standards
Authority of Ireland (section 28) (13A plugs and Conversion Adaptors for Domestic Use)
Regulations, 1997.
Spain
Supply cords of single-phase equipment having a rated current not exceeding:
– 10A shall be provided with a plug according to UNE 20315:1994
CLASS I EQUIPMENT provided with socket-outlets with earth contacts, or which are intended
to be used in locations where protection against indirect contact is required according to the
wiring rules, shall be provided with a plug in accordance with UNE 20315:1994
