Specifications
Specifications - SHEDs
Environment
Dimensions (L x W x H) .................................................................................. 7.5" x 1.9" x 2.5"
Weight ........................................................................................................................................ 1 lb.
Temperature Range ........................................................................................... -20 C to +55 C
Humidity Range ...........................................................................0 to 95% non-condensing
Connectors
HYBRID (SMPTE) .................................. LEMO (SMPTE 304M) standard, Fisher optional
Optical ...........................................................Two ST type, singlemode (others available)
Power Consumption............................................................................................
Base Station unit ........................................................................................ Less than 20 Watts
Camera unit ................................................................................................. Less than 20 Watts
Transmission
Transmission Method..................................................As determined by camera system
Fiber Types ...............................................................................................................Single-Mode
Wavelength (from/to cam)............................................................................. 1300/1550 nm
Representative Fiber Specifications
Fiber Type........................................................................................Single Mode (SM) 9/125μ
Attenuation Factor ..............................................................................0.5 dB/km @ 1300 nm
Specifications - SHED-6
Environment
Dimensions (L x W x H) ................................................................................... 17.5" x 1.9" x 7"
Weight ........................................................................................................................................ 2 lb.
Temperature Range ........................................................................................... -20 C to +55 C
Humidity Range ...........................................................................0 to 95% non-condensing
Power Consumption
.......................................................................................................................... Less than 20 Watts
All other Specifications remain the same as for SHED.
Specifications - HDX
Environment
Dimensions (L x W x H) ................................................................................... 13" x 3.4" x 8.4"
Weight ...................................................................................................................................8.5 lbs.
Temperature Range ........................................................................................... -20 C to +55 C
Humidity Range ...........................................................................0 to 95% non-condensing
