Specifications
Table 3. Performer-HD Specifications
Matrices
Serial Digital Video One 10x1
Audio Two 10x1 AES/EBU
Video/Data Inputs
Type Serial Digital conforming to SMPTE 292M or 10Mbps to 700 Mbps (non-reclock mode)
Impedance 75 Ohm
Quantity 10 Non Looping
Connector 75 Ohm BNC
Return Loss >15 dB to 1.485 GHz
Cable Equalization Automatic for up to 100m of Belden 1694A @ 1.485 Gbps
Video/Data Outputs
Type Serial Digital conforming to SMPTE 292M or 10Mbps to 700 Mbps (non-reclock mode)
Impedance 75 Ohm
Quantity 1 Dual
Connector 75 Ohm BNC
Return Loss >15 dB to 1.485 GHz
Audio/Data Inputs
Type Serial Digital conforming to standard AES3-1992 (ANSI S4.40-1985)
Impedance 75 Ohm, ±5%, 100KHz to 6MHz (BNC connector)
Quantity 10 per Audio Matrix (20 Total)
Level 400mV
Connector Type Unbalanced 75 ohm BNC
Audio/Data Outputs
Type Serial Digital conforming to standard AES3-1992 (ANSI S4.40-1985)
Quantity 1 dual per AES matrix
Level 1.0Vp-p ±10% into 75 Ohm BNC Connector
Connector Type Unbalanced 75 ohm BNC
Operational Modes/Performance
Video Path Delay Span 6.60nS +/- 0.5nS, Reclocked.
5.75nS +/- 0.5nS, Non Reclocked
Data Rates Supported 1.485 Mbs reclocked or10Mb/sec to 700Mb/sec non reclocked
