Connect your presenter system, Installing the camera system, Chapter 2 connect your presenter system – Grass Valley 3-CCD CameraMan Rev.C User Manual
Page 19
071838600
June 2005
13
Installing the Camera System
Now that you’ve identified the components of your
Presenter Camera System, as well as their individ-
ual buttons, ports and jacks, you can begin connect-
ing them to your CameraMan camera.
Removing the Camera-
Man Connector Block
(Upgrade Only)
FIGURE 2.1
Connector Block and CameraMan
If you are performing an initial installation of a sys-
tem package, as opposed to an upgrade, this is not
necessary.
Chapter 2
Connect Your Presenter System
