REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
INCLUDES ITEMS 2-14
STARTER ASY
1
A051000591
1
SPRING, PAWL RETURN
2
P022004610
2
PAWL, STARTER
2
P022004620
3
CASE, STARTER
1
P022006500
4
SPRING, REWIND
1
P022004680
5
DRUM, STARTER
1
P022004690
6
REPOWER BULK OPTION: 99944440000
ROPE, STARTER - 3X800mm
1
1
P022004600
7
GRIP, STARTER
1
P022004990
8
CLIP, ROPE
1
17724611120
9
SPRING, RETURN
1
P022004660
10
SPRING PAWL
1
P022004670
11
SPRING ASY
1
P022004700
12
PLATE, CAM
1
P022004640
13
SCREW
1
P022004630
14
SCREW 5X20
3
90025305020
15
LABEL,
1
X502000032
16
LABEL - MODEL -- TC-210i
1
X503004630
17
INCLUDES ITEMS 19-21
STARTER PAWL ASY
1
A052000150
18
PAWL, STARTER
2
P022004740
19
SPRING, PAWL RETURN
2
P022006510
20
E-RING
2
P022002100
21
INCLUDES ITEM 23
TANK, FUEL
1
13100511821
22
SPACER
3
13104528230
23
SCREW 5X15
3
90027505015
24
VENT ASY
1
A356000030
25
CLIP
1
13011100530
26
REPOWER BULK OPTION: 90014
PIPE, VENT - 3X5X70mm
1
V471001200
27
REPOWER BULK OPTION: 90017
PIPE, RETURN - 3X6X50mm
1
13201049030
28
REPOWER BULK OPTION: 90014
PIPE, FUEL - 3X5X210mm
1
V471001230
29
GROMMET
1
V137000030
30
CLIP
1
13201309820
31
FILTER, FUEL
1
13120507320
32
INCLUDES ITEMS 34-35
CAP ASY
1
13100455530
33
GASKET, CAP
1
13101655830
34
CONNECTOR, CAP
1
13105156030
35
INCLUDES ITEMS 37-39
CLUTCH ASY
1
17500007531
36
HUB, CLUTCH
1
17501605020
37
SPRING, CLUTCH
2
17501805130
38
SHOE, CLUTCH
2
17500905131
39
PLATE, CLUTCH
1
17501904630
40
WASHER 10
1
90060000010
41
BEARING, BALL
1
90080836000
42
DRUM, CLUTCH
1
17501004633
43
WASHER, CLUTCH
1
17504404630
44
WASHER, CLUTCH
1
17501411520
45
SCREW 6X12
1
90023806012
46
CASE, CLUTCH
1
61022311520
47
SCREW 4X14
4
90023804014
48
BOLT
1
13041611520
49
Footnotes
1: BULK OPTION: 99944444000
99922203521_210i/09
- 7 -
REVISED 05/01/08
TC-210i Tiller Cultivator
Fan Case, Fuel System, Clutch
