REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
CARBURETOR -- C1U-K82
1
A021001090
0
SCREW, PURGE BASE
4
P005000980
1
RETAINER, PURGE BULB
1
P005000620
2
BULB, PURGE
1
12538108660
3
BASE, PURGE
1
P005000970
4
NOT AVAILABLE SEPARATELY
BODY, CARBURETOR
1
-------------------
5
NOZZLE, CHECK VALVE
1
12537613120
6
CAP, MIXTURE LIMITER - HIGH SPEED
1
12532939030
7
NEEDLE - HIGH SPEED
1
12532013310
8
CAP, MIXTURE LIMITER - LOW SPEED
1
12532909860
9
NEEDLE - LOW SPEED
1
12531813120
10
SWIVEL
1
12537242030
11
SHAFT, THROTTLE
1
P005001070
12
CLIP, THROTTLE SHAFT
1
12532713930
13
SPRING, THROTTLE RETURN
1
12531342030
14
SCREW, THROTTLE VALVE
1
12531413930
15
VALVE, THROTTLE
1
12531649030
16
CLIP, THROTTLE SHAFT
1
12532715130
17
COVER, FUEL PUMP
1
12532412820
18
SCREW, IDLE ADJUST
1
12533406960
19
SPRING, IDLE ADJUST
1
12533306960
20
SCREW, FUEL PUMP COVER
2
12531012820
21
SCREW, METERING LEVER PIN
1
12533942030
22
INCLUDES ITEMS 24-33
REPAIR KIT
1
12530013120
23
DIAPHRAGM, METERING
1
-------------------
24
GASKET, METERING DIAPHRAGM
1
-------------------
25
PIN, METERING LEVER
1
-------------------
26
LEVER, METERING
1
-------------------
27
VALVE, INLET NEEDLE
1
-------------------
28
WELCH PLUG
1
-------------------
29
SPRING, METERING LEVER
1
-------------------
30
STRAINER
1
-------------------
31
DIAPHRAGM, FUEL PUMP
1
-------------------
32
GASKET, FUEL PUMP
1
-------------------
33
INCLUDES ITEMS 35-38
GASKET/DIAPHRAGM KIT
1
12530313120
34
DIAPHRAGM, METERING
1
-------------------
35
GASKET, METERING DIAPHRAGM
1
-------------------
36
DIAPHRAGM, FUEL PUMP
1
-------------------
37
GASKET, FUEL PUMP
1
-------------------
38
99922203521_210i/09
- 11 -
REVISED 05/01/08
TC-210i Tiller Cultivator
Carburetor -- C1U-K82
