Echo CULTIVATOR TC-210I User Manual
Page 13
REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
HANDLE, UPPER
1
35101013351
1
GRIP, HANDLE - LEFT
1
35131102330
2
GRIP, HANDLE - RIGHT
1
35131527930
3
CLIP
2
17811113350
4
BRACKET, THROTTLE
1
17802408730
5
SCREW
1
17811005330
6
LOCKNUT
1
90056000005
7
SCREW 5X25
1
90022005025
8
NUT 5
1
90050000005
9
SPRING, THROTTLE RETURN
1
17804305230
10
TRIGGER, THROTTLE
1
17801006460
11
CABLE, THROTTLE
1
17800111520
12
E-RING
1
V583000020
13
NUT 6
2
90050200006
14
LOCKWASHER 6
2
90061000006
15
BRACKET, SWITCH
1
16381013350
16
SCREW 5X10
1
90025305010
17
SWITCH, IGNITION
1
16340002160
18
LEAD, GROUND
1
V485000251
19
TUBE, VINYL
1
17812750330
20
TIE STRAP
2
17812143230
21
BRACKET, HANDLE
1
35131213350
22
BOLT 1/4X1-1/4
2
90001708040
23
LOCKNUT 1/4
4
90003100008
24
SPRING WASHER
6
16389213350
25
LABEL, CAUTION -- TC-210
1
89016011760
26
LABEL, CAUTION -- TC-210i
1
X503004700
27
HANDLE, LOWER - LEFT
1
35121013350
28
HANDLE, LOWER - RIGHT
1
35111013350
29
BOLT 1/4X1-1/4
2
90001808040
30
NUT 1/4
2
90003208032
31
HANDLE, FRONT
1
30581113350
32
EYE PLATE
2
69401113350
33
BOLT 1/4X3
1
90001708096
34
BOLT 1/4X3-1/4
1
90001708104
35
SHEILD, BLADE
1
69401013351
36
BOLT 1/4X1/2
2
90002108016
37
LABEL, CAUTION
1
X505001210
38
DRIVESHAFT
1
60531012350
39
HOUSING, WORM GEAR
1
60541012350
40
ROTOR, CULTIVATOR - LEFT
1
69001113350
41
RETAINER, BEARING SEAL
2
60542813350
42
SEAL, BEARING
2
60541713350
43
BEARING, WORM GEAR
2
60422113350
44
SHAFT, TINE
1
60531413350
45
ROTOR, CULTIVATOR - RIGHT
1
69001013350
46
SNAP PIN
2
60561213350
47
COVER, HOUSING
1
66002012350
48
SCREW
4
90008200100
49
GASKET, HOUSING COVER
1
60541212350
50
THRUST WASHER, WORM GEAR
2
60531613350
51
GEAR, WORM
1
60531513350
52
BEARING
1
60541813350
53
RACE, WORM BEARING
2
60532413350
54
THRUST BEARING, WORM SHAFT
1
60543313350
55
SHAFT, WORM
1
60531313350
56
99922203521_210i/09
- 13 -
REVISED 05/01/08
TC-210i Tiller Cultivator
Handle, Stop Switch, Throttle Cable
