HD Fibre adapter LDK 5476 | Specifications 4
2 Specifications
Table 1 LDK 5476 HD Fibre adapter
Item Value
Power requirements Fibre powered or 12 Vdc
Operating temperatures -20 to +45°C (-4 to +113°F)
Storage temperatures -20 to +60°C (-4 to +140°F)
Weight (approx.) 2.3 kg
Dimensions 220 (L) x 120 (W) x 205 (H) without handgrip
Fibre in/out Lemo hybrid optical connector (SMPTE 304M)
Fibre attenuation > 12.5 dB
Fibre cable Hybrid cable (SMPTE 311M)
Length 4000m (13,000ft.) max.
Intercom XLR5/Tuchel with channels ENG/PROD/PROG
Video (CVBS) out Optional: 1 Vpp; 75 Ohm; BNC
Video telepromter out 1 Vpp; 75 Ohm; BNC
Monitor (Y) 1 Vpp; 75 Ohm; BNC
Reference in 1 Vpp; 75 Ohm; BNC
Tracker 11 pins Communication / Signalling
Auxilary/ Data 11 pins private data
Rear microphone in (2x) XLR 3, balanced, +48V
DC12Volts in XLR-4 male
Scriptlight power 12 Volts, 0,25A, 3-pin Fisher
DC12Volts out 4-pin Fisher 1.5 Amp.
