Grass Valley 8945EDA v.1.3.0 User Manual
Page 17
8945EDA/-D — Instruction Manual
17
Cabling
Figure 5. 8945EDA Rear Cabling
Figure 6. 8945EDA-D Rear Cabling
8900WE-R
J9: Video Input
J7: Video Output
J5: Video Output
J1: Video Output
J3: Video Output
J10: Not Used
J8: Video Output
J6: Video Output
J4: Video Output
J2: Video Output
8436_01r0
8900WE-R
J9: Video Input 1
J1: Video Output
J3: Video Output
J5: Video Output
J7: Video Output
J10: Video Input 2
J2: Video Output
J4: Video Output
J6: Video Output
J8: Video Output
8436_02r0
