LDK 5307 7-inch LCD HD color viewfinder User’s Guide (v3.1) 33
Chapter 4 - Viewfinder setup
4.1.8 Box setup menu (BOX)
4.2 Viewfinder status information
The status information screen shows information about the viewfinder’s internal
hard- and software components. This information can be useful when contacting
Grass Valley service support. Press EXIT to leave this screen.
Control Item Value(s) Description
Menu EXIT BOX Exits the box menu.
Button1 Box Off, Box, Line,
Full Selects the box type.
Button2 Color Whit, Red, Grn,
Blue, Yell,
Mgnt, Cyan Selects the line color of the box.
Button3 Side T/B > L/R Selects the side of the box to be adjusted:

T/B = Top/Bottom; L/R = Left/Right
Rotary1 Top 0..99 (24) Sets the top position of the box.
Rotary2 Bottom 0..99 (73) Sets the bottom position of the box.
Rotary1 Left 0..99 (24) Sets the left position of the box.
Rotary2 Right 0..99 (74) Sets the right position of the box.
Rotary3 PREV
↑
NEXT
↓
Selects a menu from the list.
EXIT
V i e w f i n d e r S t a t u s I n f o r m a t i o n
Type: LDKxxxx
Package: 12NC: 3922 407 xxxxx vxx.xx Date: xx/xx/xx
Firmware: 12NC: 3922 407 xxxxx vxx.xx Date: xx/xx/xx
Main Brd: 12NC: 3922 406 xxxxx St: xx Date: xx/xx/xx
PID: xxxxx
Appl.Sw: 12NC: 3922 407 xxxxx vxx.xx Date: xx/xx/xx
Conf.Sw: 12NC: 3922 407 xxxxx vxx.xx Date: xx/xx/xx
PID: xxxxxx
