LDK 5307 7-inch LCD HD color viewfinder User’s Guide (v3.1) 29
Chapter 4 - Viewfinder setup
Chapter 4
Viewfinder setup
4.1 Menu contents
The following tables show the items and functions that can be set up in the
viewfinder setup menu.
4.1.1 Diagnostics menu (DIAG)
Control Item Value(s) Description
Menu EXIT DIAG Exits the diagnostics menu.
Button1 STATUS INFO Go to the viewfinder status information
screen. More information can be found in the
paragraph
“Viewfinder status information” on
page 33 .
Button2 — — —
Button3 — — —
Rotary1 Format formats> Info: shows the current video format.
Rotary2 VF Temp nn C Info: shows the current operating
temperature in degrees celsius.
Rotary3 PREV
↑
NEXT
↓
Selects a menu from the list.
