LDK 5307 7-inch LCD HD color viewfinder User’s Guide (v3.1)
15
Chapter 2 - Installation
Chapter 2
Installation
2.1 Mounting the viewfinder
To mount the viewfinder on top of the camera adapter proceed as follows:
1.
Switch off the camera.
2.
Slide the V-block of the viewfinder onto the quick mount block on the camera
adapter until it clicks firmly into place.
3.
Connect the viewfinder cable to the viewfinder connector on the camera head.
Guide the cable along the top of the camera body.
release
lever
V-block
Quick
mount
block
