LDK 4021 HDTV 7-inch high brightness viewfinder - User’s Guide (v2.0)
13
Chapter 2
Adjusting
2.1 Positioning
The viewfinder can be easily positioned to adapt to any viewing angle and situation. There are
four position adjustments:
•
backwards and forwards,
•
tilt,
•
lift, and
•
rotate.
2.1.1 Backwards and forwards
1.
Loosen the viewfinder mount retaining lever on top of the SuperXpander.
2.
Slide the viewfinder support mount along the rails until it is in the desired position.
3.
Tighten the viewfinder retaining lever on top of the SuperXpander.
