9
Activating licenses
Logging in to the SSL VPN management page
Before you log in to the SSL VPN web management page, access the SSL VPN command line interface
through the console port of the SecBlade SSL VPN card to perform basic configuration. For more
information about logging in to the SSL VPN management page, see Step-by-Step Configuration of H3C
SSL VPN.
Step1 Connect the devices.
• Use a console cable to connect the serial port of your PC to the console port of the SSL VPN card.
• Use a crossover Ethernet cable to connect the PC to a service interface on the network device (an
S7500E switch or an SR6600 router for example) that hosts the SecBlade SSL VPN card.
Figure 10 Connect the devices
Device
SecBlade SSL VPN
PC
Console
Ethernet
Step2 Configure the terminal emulation program on your PC.
Run a terminal emulation program, such as Terminal in Windows 3.X or HyperTerminal in Windows 9X
and Windows XP.
Set the terminal communication parameters as follows:
• Baud rate—9600 bps
• Data bits—8
• Parity—None
• Stop bit—1
• Flow control—none
NOTE:
Values for the terminal communication parameters depend on the device model.
Step3 Configure the SecBlade SSL VPN card at the command line interface through the console port. The SSL
VPN service is enabled by default.
• Assign an IP address, 192.168.1.1/24 for example, to the internal interface that connects the card
to the network device.
• Configure a static route to the PC, for example, ip route-static 192.168.0.0 24 192.168.1.2.
