1. While holding the molded hose steady just below the Trim Grip™ (Figure 5a),
grasp and turn the Trim Grip™ 1/4 turn clockwise (Figure 5b). Next, pull down
on the molded hose to disengage the lower assembly (Figure 5c).
2. remove the port plug from a medium
pressure (MP) port on the regulator using
an appropriately sized wrench (Figure 3).
3. check to ensure the hose o-ring is present and
in good condition, tighten the threaded end of
the hose into the port. Torque to 40 inch-pounds
(4.5 Nm) with a 9/16" wrench (Figure 4).
4. Secure buoyancy compensator to cylinder and attach first stage regulator
to cylinder valve.
5. check to ensure the connection o-ring on the lower assembly is present
and in good condition.
Figure 3
Figure 4
Figure 5b Figure 5a Figure 5c
The Airsource is specifically designed so that the lower unit can be easily
detached and stored with your regulator.
Removal/Replacement of the Airsource from the Trim Grip
