Installation Guide
5
Step 3: Connect the Cable
1. If the cable will pass through the hole on the surface, route the network cable through the
hole. If the cable will go along the surface, remove the cable exit tab on the camera and
route the cable along the surface.
Cable Passing Through a Hole on the Surface Cable Going Along the Surface
2. Connect the network cable to the Ethernet port of the camera.
or
