Page 8
8
a
ssembly
A
A
lower
drIve
shafT
assembly
To
deThaTCher
gear
housIng
Parts Required: Dethatcher Gear Housing, Lower Drive Shaft with
Fender
/
Wheel
Assembly
1. Place dethatcher gear housing on a flat surface with gear housing
shaft mount at 45
°
angle.
2. Remove gear housing shaft alignment screw (A.
3. Loosen gear housing shaft mounting bolt (B).
A
B
95 mm
B
C
Parts Required: Lower Drive Shaft Assembly, Fender /
Wheel
Assembly
1. Remove vinyl cap from lower end of drive shaft tube.
2. Loosen two (2) fender/wheel assembly bracket bolts (A). The bolts
should be very loose to prevent bracket from damaging locating
arrow decal label.
3. Install fender/wheel assembly, fender side first, onto end of lower
drive shaft without serial number label. End of drive shaft should
be 95 mm (3.74 in.) from fender clamp. Assure locating hole (B) is
facing upward, and locating arrow decal (C) is aligned with edge of
fender clamp.
4. Tighten bolts (A).
fender
/
wheel
assembly
To
lower
drIve
shafT
assembly
WARNING
Do not perform maintenance or assembly procedures with engine running.
