2

INTRODUCTION

This handy switch is designed to pass both data and electrical power to a number

of PoE-compatible devices via standard Cat5e or Cat6 network cables.
Easy-to-follow instructions in this user manual help make installation quick and

simple, so you’ll also soon be enjoying the benefits of these additional features:

• 10/100/1000 auto-sensing ports automatically detect optimal network speeds

• IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports

• Power output up to 30 Watts per port*

• Total power budget of 130 Watts

• Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless

access points, VoIP phones, IP cameras)

• Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage

protection

• All RJ45 ports with Auto-MDIX (auto uplink) support

• Web-based configuration

• Provides detailed traffic and power use statistics

• Supports SNMP management

• Supports VLAN (tag-based and port-based)

• Provides IEEE 802.1x port-based security

• Supports link aggregation (trunking)

• Supports port mirroring

• Supports two types of QoS: 802.1p and DSCP

• Broadcast storm control with multicast packet rate settings

• Store and forward switching architecture

• Supports jumbo frames up to 9.6 kBytes

• Supports Rapid Spanning Tree/Spanning Tree protocol

• IEEE 802.3x flow control for full duplex

• Supports up to 8192 MAC address entries

• 176 kBytes buffer memory

• Desktop-size metal case

* Total PoE budget for this switch is 130 watts. Per-port average power distribution

is 15 Watts; maximum per-port power usage cannot exceed 30 Watts.

Some of the following screen images have been modified to fit the format of this

user manual.

NOTE: For a quick install procedure, refer to the quick install guide enclosed with

this product.
