PAS 80 T

ooTh

B

lAde

T

rimmer

A

TTAchmenT

o

PerATor

'

S

m

AnuAl

7

C

onTenTs

After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing

parts. Use the contents list to check for missing parts.

___ 1 - Pro Attachment Series

TM

Brushcutter Attachment

___ 1 - Operator's Manual

___ 1 - Warranty Registration Card

___ - Assembly Tool (s)

___ 1 - 80 Tooth Metal Blade

___ 1 - Metal shield

___ 1 - Shield bracket

___ 1 - 4-Hole Barrier Bar

___ 1 - 2-Hole Barrier Bar

___ 3 - 5mm x 10mm screws (shield mounting)

___ 2 - 5mm x 8mm screws (bracket mounting)

___ 4 - 5mm nuts (bracket mounting)

___ 4 - 5mm lockwashers (bracket mounting)

___ 4 - 5mm x 35mm bolts (barrier bar)

___ 4 - 5mm nuts (barrier bar)

___ 9 - Split pins

___ 1 - Storage Hook Assembly

___ 1 - Shoulder Harness w/Quick-release Hook

1. LOWER DRIVE ShAFT ASSEMBLy - Includes the Debris Shield Assembly, Gear Housing assembly, Flexible

Drive Cable, Metal Blade and Safety Decals.

2. FLEXIBLE DRIVE CABLE - Cable end fits into upper drive shaft coupler. Lubricate drive cable every 25 hours

with ECHO

®

LUBE

TM

grease.

3. METAL BLADE ShIELD - Required when unit is equipped with blades. Do not operate unit without shield.

4. BLADE - Circular blade for brush cutting applications. Harness, metal shield and U-handles required for blade

operation.

Shaft Decals

Debris Shield Decal
