Echo PAS 80 Tooth Blade Brushcutter User Manual
Page 10

10
balanCe
unIT
1. Put on harness and attach unit to harness.
2. Slide harness clamp up and down until unit balances with head ap-
proximately 2 - 3 in. from the ground.
3. Tighten clamp screw.
NOTE
In case of Emergency, the trimmer/brushcutter can be released from
the the harness by pulling up on the quick-release collar.
2 - 3"
NOTE
Refer to the Grass Trimmer / Brush Cutter Safety Manual for proper and safe trimming techniques.
o
peraTIon
WARNING
Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all
openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete
stop before removing obstructions, clearing debris, or servicing unit.
