4 6608-2211
1 SPECIFICATIONS LR-11/LR-11PP
GENERAL
F I B R E
Maximum fibre length 25 000 m (between two LR-11 units)
T E C H N I C A L D A T A
Transmission Routing of LonTalk ® ‚ packets using Echelon RTR-10 router core
Interface 1 L ON W ORKS ® TP/FT, FTT-10A, 5-position screw block
Interface 2 See model specific data
Indicators See model specific data
Transmission rate L ON W ORKS ® TP/FT 78 kbit/s
Fibre optic 1 250 kbit/s
Weight, kg 0.3 kg
Mounting On 35 mm DIN-rail
P O W E R S U P P L Y A L T E R N A T I V E S
Model description LR-11/LR-11PP HV LR-11/LR-11PP LV
Power supply 95–240 V AC ± 10% 12–45 V AC ± 10%
110–240 V DC ± 10% 12–55 V DC ± 10%
Frequency 48–62 Hz / – 48–62 Hz / –
Fuse, F2 1 A T Wickmann 1 A T Wickmann
Power consumption 40 mA 4 W
Transient protection
Power/Line Yes/Yes Yes/Yes
Isolation RMS
Power supply 3 750 V 3 750 V
M O D E L S P E C I F I C D A T A
LR-11 LR-11PP
Interface 2 Fibre optic, Fibre optic,
4 ST-connectors, 2 ST-connectors,
See Power budget table on page 14 See table on page 14
Indicators PWR, TD, RD, Tx1, Tx2, PWR, TD, RD, ASRV, BSRV
Rx1, Rx2, ASRV, BSRV
L E D I N D I C A T I O N
LED FUNCTION
PWR Indicates that the unit has power
TD Indicates transmitting data on fibre side
RD Indicates transmitting data on TP/FT side
Rx1 Indicates receiving data on fibre receiver 1
Tx1 Indicates transmitting data on fibre transmitter 1 from TP/FT side
Rx2 Indicates receiving data on fibre receiver 2
Tx2 Indicates transmitting data on fibre transmitter 2 from TP/FT side
ASRV Indicates status on router side A (TP/FT)
OFF: Side A configured
ON: An unrecovered error has been detected on side A
Flashing (1 Hz): Side A unconfigured
BSRV Indicates status on router side B (fibre optic)
OFF: Side B configured
ON: An unrecovered error has been detected on side B
Flashing (1 Hz): Side B unconfigured
