Continued
MLC 104 IP Plus
MediaLink ™ Controller with IP Link ®
unique Features
• Two-gang faceplate
• MR 200 Mud Ring included
MLC 104 IP Plus AAP
MediaLink ™ Controller with IP Link ® and AAP Opening
unique Features
• Four-gang faceplate
• Opening for up to four single space AAP - Architectural Adapter
Plates; AAPs sold separately
• MR 400 Mud Ring included
MLC 104 IP Plus DV+
MediaLink ™ Controller with IP Link ® and Integrated DVD and
VCR IR Control
unique Features
• Four-gang faceplate
• Dual-function DVD and VCR IR control
• Includes black and white, high-impact plastic mounting faceplates
• Black and white MR 400 Mud Rings included
MLC 104 IP Plus Controller Only
MediaLink ™ Controller with IP Link ® - Controller Only -
No Faceplate
unique Features
• No faceplate for custom installations
• For use with any of the MLM 104 Series mounting options
MLC 104 IP Plus L
MediaLink ™ Controller with IP Link ® and Lectern Faceplate
unique Features
• Low profile, 3.2" (8.1 cm) tall faceplate fits into a compact space on a lectern
or desk
• Mounts in a rack or wall using an Extron UCM RAAP or UCM 10X8P Universal
Controller Mounting Kit; mounts on a desk using an Extron SMB 203 L Lectern
Series Mount Box
MLC 104 IP Plus Series
M e d i a L i n k ™ c o n t r o L L e r s
ModeL
Version desCriPtion Part #
MLC 104 IP Plus Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-02
MLC 104 IP Plus White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-03
MLC 104 IP Plus RAL9010 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-05
ModeL
Version desCriPtion Part #
MLC 104 IP Plus AAP Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-12
MLC 104 IP Plus AAP White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-13
MLC 104 IP Plus AAP RAL9010 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-15
ModeL
Version desCriPtion Part #
MLC 104 IP Plus DV+ Black & White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-82
ModeL
Version desCriPtion Part #
MLC 104 IP Plus Controller Only Controller Only - No Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-00
ModeL
Version desCriPtion Part #
MLC 104 IP Plus L Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-32
MLC 104 IP Plus L White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-33
MLC 104 IP Plus L RAL9010 White . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-818-35
