Adjusting the Monitor's Display
The monitor has four function control buttons to select among functions shown on OSD menu,
designed for easy user-viewing environments.
OSD Function Menu
To access the OSD Main menu, simply press one of
the Function Select control buttons, and the menu
diagram will pop up on the screen as shown on Fig.
2-2:
Continue pressing the Function Select buttons to
scroll through the available menu items, then press
the Adjustment Control buttons to adjust the setting
of a selected item.
Figure 2-2
Function Description
Icon
Function Function Description
Brightness This function lets you increase and decrease the screen brightness.
Contrast
This function lets you increase and decrease the contrast level of the
screen.
H. Position
This function let's you adjust the display's horizontal position. (Not
available when using DVI).
V. Position
This function let's you adjust the display's vertical position. (Not
available when using DVI).
Sharpness
This function let's you adjust the images sharpness. Five selections are
available. A smoother setting is more suitable for pictures, while a
sharper setting is more suitable for text. (Not available when using DVI).
OSD
Transparency
This function let's you set the transparency of the OSD menu (Not
available when using DVI).
Phase
This lets you adjust the phase of the pixel clock to eliminate sampling
noise (Not available when using DVI).
Clock
Adjusts the sampling frequency for the Analogue (VGA) to Digital signal
conversion (Not available when using DVI).
