Parts List, Motor Assembly, Electric, 110 VAC (P/N 58-0184)
Item Part
No. No.
Description
Qty
1.
20-0617
SHAFT, DRIVE
1
2.
20-0619
SHAFT, DRIVE, 1/2-20 UNF
1
3.
28-0245
SEAL, GREASE
1
4.
28-0233
O-RING
2
5.
31-0115
KEY, ROUND ENDS
1
6.
33-0041
SCREW, CAP, 1/4-20 X 7/8"
1
7.
33-0619
SCREW, SET, #10-32 X 1/4", CUP PT
1
8.
39-0005
WORM
1
9.
45-0221
BUSHING, FLANGE, 5/8" ID
2
10.
46-0586
SLEEVE, MOTOR
1
11.
47-1111
BRACKET CLAMP
1
12.
54-0347
PLUG
1
13.
58-0183
MOTOR, ELECTRIC, MOD, 110 VAC (Milwaukee)
1
NOT SHOWN
33-0292
SCREW, BUTTON, 5/16-18 X 5/8"
REF
Parts List, Motor Assembly, Metabo, 110 VAC (P/N 58-0301)
Item Part
No. No.
Description
Qty
1.
20-0617
SHAFT, DRIVE
1
2.
20-0619
SHAFT, DRIVE
1
3.
28-0245
SEAL, GREASE
1
4.
28-0233
O-RING
2
5.
31-0115
KEY, ROUND ENDS
1
6.
33-0041
SCREW, CAP, 1/4-20 X 7/8"
1
7.
33-0619
SCREW, SET, #10-32 X 1/4", CUP PT
2
8.
39-0005
WORM
1
9.
45-0258
BUSHING, FLANGE, 5/8" ID
2
10.
46-0411
SLEEVE, MOTOR
1
11.
47-1111
BRACKET CLAMP
1
12.
54-0347
PLUG
1
13.
58-0277
MOTOR, C.W.ELEC., METABO, 110V
1
NOT SHOWN
33-0292
SCREW, BUTTON, 5/16-18 X 5/8"
REF
