Tri Tool 214B Elbow Mandrel User Manual
Page 8
8
TRI TOOL INC.
92-1502 : Orig. 100923
Material
Hardened steel contact pins.
"B" Maximum DIA
"A" Minimum DIA
Envelope Drawing with ID Mounting Ranges
14.00" (355.6 mm)
Model 214B EM Kit
Model 214B
BEVELMASTER
®
NOTE:
Correct Pin Length is important for rigidity. Use only the correct Contact
Pins specified for each head size.
Contact Pin Point of Measure
Point of
Measurement
