www.desatech.com 113110-01A 35
PARTS LIST
REMOTE-READY MODELS
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 33 of this manual.
PART NUMBERS
KEY VMH26PRB VMH26NRB
NO. EFS26PRA EFS26NRA DESCRIPTION QTY.
1 102633-02 102633-02 Outer Casing Top 1
2 102624-02 102624-02 Outer Casing 1
3 099230-02 099230-02 Shoulder Screw 14
4 098304-01 098304-01 Screw, #10 x 3/8" 13
5 109824-05 109824-05 Burner 1
6 098304-02 098304-06 Screw, PPH AB 6-20 x .38 4
7 102635-02 102635-02 Left and Right Side Front 2
8 103209-05 103209-05 Louver 2
9 104281-02CK 104281-02CK Firebox Hood 1
10 102638-01 102638-01 Firebox Top 1
11 103778-01 103779-01 ODS/Pilot Assembly 1
12 ** ** Firebox Wrapper 1
13 104322-01 104322-01 Burner Tube 1
14 104335-01CK 104335-01CK Outer Shell Base 1
15 102649-02 102649-02 Branch Support 1
16 102445-01 102445-01 Piezo Ignitor 1
17 — 099918-02 Regulator, Pilot 1
18 098271-10 098271-10 Ignitor Cable 1
19 107186-01 107186-02 Injector 1
20 M11084-26 M11084-26 Screw, Hex Head, #10 x 3/8" 25
21 098249-01 098249-01 Nut, M5 6
22 103781-02 103781-01 Gas Valve 1
23 102639-01 102639-01 Baffle 1
24 101628-01 101628-01 Flexible Connector 1
25 104305-01 104305-01 Control Shield 1
26 103295-03CK 103295-03CK Screen Assembly 1
27 107153-01 107153-01 Log Set Assembly Kit 1
28 104313-01 104313-01 Right Hinge 1
29 104313-02 104313-02 Left Hinge 1
30 M10908-2 M10908-2 Hinge Screws 4
31 103734-01 103734-01 Burner Support 2
32 101006-02 101006-02 Pilot Bracket 1
33 097809-02 097809-02 Connector, Male 1
34 101629-01 101629-01 Bushing 1
35 101629-02 101629-02 Bushing 1
36 M12461-26 M12461-26 Gas Valve Screws 4
37 103587-02 103587-02 Plate, Switch 1
38 099998-01 099998-01 Switch, Fan 1
39 098264-02 098264-02 Connector, Male 1
40 103284-03 103284-03 Wire Harness 1
41 — 099387-14 Pilot Tube to Regulator 1
42 099387-13 099387-15 Pilot Tube to Control Valve 1
43 ___ 107634-02 NG Conversion Plate 1
44 M10908-75 M10908-75 Hex Wsr Head Tapping Screw 1
PARTS AVAILABLE — NOT SHOWN
103877-01 103877-01 Lighting Instructions Plate 1
100563-01 100563-01 Warning Plate 1
103470-02 103470-02 Hardware Package 1
** Part not available for field replacement.
