Model 76D/77 User Guide Issue 11, May 2014
Studio Technologies, Inc. Page 51
for Surround
Appendix A—Connection Pin-Out
Charts
TASCAM® Signal Signal
Connections Channel High (+) Low (–) Shield
Pre-Fader L/R 1 24 12 25
Pre-Fader C/SUB 2 10 23 11
Pre-Fader LS/RS 3 21 9 22
Stereo Input C Direct 4 7 20 8
Post-Fader L/R 5 18 6 19
Post-Fader C/SUB 6 4 17 5
Post-Fader LS/RS 7 15 3 16
Post-Fader Stereo 8 1 14 2
Notes: 1) All signals transformer-coupled digital audio;
selectable for balanced or unbalanced AES3
compatibility.
2) Connector type on Model 76D is 25-pin female
D-subminiature (DB-25F). Installer must provide male
(DB-25M). Connector uses 4-40 threaded inserts for
locking with mating plug.
3) Wiring scheme follows TASCAM DA-88 convention.
Standard DA-88-type wiring harnesses are directly
compatible, with the possible exception of 4-40
screw threads being required.
Connections for Digital Monitor Outputs
Signal Pin Direction
Data + (RS-485/RS-422) 7 Not used
Data – (RS-485/RS-422) 2 Not used
Data Shield 1 Shield
Remote Mute All 5 Input
Remote Dim 6 Input
Remote Spare 1 8 Input
Remote Spare 2 9 Input
Remote Input Common 4 Common
Note: Connector type on Model 76D is 9-pin female
D-subminiature (DE-9F). Connector uses 4-40
threaded inserts for locking with mating plug.
Connections for Remote Control Inputs
Signal Pin Direction
Data + (RS-485) 1 To/From Models 77/71
Data – (RS-485) 6 To/From Models 77/71
Data Shield 2 To/From Models 77/71
DC + (12 V) 4 To Models 77/71
DC – (12 V Return) 9 To Models 77/71
DC Power Shield 5 To/From Models 77/71
Note: Connector type on Model 76D is 9-pin female
D-subminiature (DE-9F). Connector uses 4-40
threaded inserts for locking with mating plug.
Connections between Model 76D and
Model 77 and Model 71
