Version B - For Reduction G016.J
®
9
Dayton Operating Instructions and Parts Manual
3VH18A and 3VH19A
1 Valve assembly 103930-02 103930-03 1
2 Nozzle 103032-02 103032-03 1
3 Control knob 099393-03 099393-03 1
4 Nozzle locator 103037-02 103037-02 1
5 Thermocouple kit 107374-01 107374-01 1
6 Piezo ignitor 102445-01 102445-01 1
7 Burner kit 106184-01 106184-02 1
8 Top disk 104145-02 104145-02 1
9 Shell 103898-03 103898-03 1
10 Base shield 106165-01 106165-01 1
11 Base 106168-01 106168-02 1
12 Emitter 106173-01 106173-01 1
13 Ignitor electrode 106174-01 106174-02 1
14 1/2 NPT to 1/4 NPT reducer bushing – 104115-01 1
15 Regulator – 103406-02 1
∆ Tradename decal 099153-14 099153-15 1
∆
Information decal 104126-04 104126-06 1
∆
Owner’s manual 106183-01 106183-01 1
∆
Indicator decal 106185-01 106185-01 1
† Regulator and hose assembly LPA3110 – 1
Reference Part No. for Part No. for
Number Description Model 3VH18A Model 3VH19A Quantity
Use only original replacement parts. This heater must use design-specific parts. Do not substitute or use
generic parts. Improper replacement parts could cause serious or fatal injuries. This will also protect
your warranty coverage for parts replaced under warranty.
Replacement Parts List
(
∆
) Not shown.
(†) Accessories
