Dayton Operating Instructions and Parts Manual
4
Dayton Propane and Natural Gas
Construction Heaters
®
3VH18A and 3VH19A
Propane Supply for Model
3VH18A
Average Temperature (ºF)
Number of
at Tank Location
Tanks (100-lbs)
60
°
2
40
°
2
32
°
2
20
°
2
10
°
3
0
°
3
You must provide propane gas and
propane tank(s).
Use this heater only with a propane vapor
withdrawal supply system. See Chapter 5
of the Standard for Storage and Handling
of Liquefied Petroleum Gas, ANSI/NFPA 58
and/or CAN/CGA B149.2. Your local library
or fire department will have this booklet.
The amount of propane gas ready for use
from propane tanks varies. Two factors
decide this amount.
1. The amount of propane gas in tank(s)
2. The temperature of tank(s)
Specifications for Model 3VH18A
Output
Minimum Fuel
Maximum Fuel
Size
Weight
Rating Btu/Hr
Fuel
Consumption
Consumption
L x W x H (Inches)
(pounds)
40,000 to 100,000
Propane
0.44 Gallons/Hour
1.1 Gallons/Hour
16 x 16 x 35
30 (Heater)
Vapor Only
1.86 Pounds/Hour
4.7 Pounds/Hour
18 x 18 x 36
35 (Shipping)
Maximum Supply
Minimum Supply
Min. Temperature
Manifold Pressure
Ignitor
Pressure to Regulator
Pressure to Regulator
Surrounding Air
(Inches of Water Column)
Gap (Inches)
200 psi
20 psi (for purposes
-20ºF (-29ºC)
13.3 (High)
0.15
of input adjustment)
25.6 (Low)
Specifications for Model 3VH19A
Output
Minimum Fuel
Maximum Fuel
Size
Weight
Rating Btu/Hr
Fuel
Consumption
Consumption
L x W x H (Inches)
(pounds)
50,000 to 100,000
Natural Gas
48 scfh
100 scfh
16 x 16 x 35
30 (Heater)
Only
18 x 18 x 36
35 (Shipping)
Maximum Supply
Minimum Supply
Min. Temperature
Manifold Pressure
Ignitor
Pressure to Regulator
Pressure to Regulator
Surrounding Air
(Inches of Water Column)
Gap (Inches)
14 inches w.c.
6 inches w.c. (for
-20ºF (-29ºC)
2.7 (High)
0.15
purposes of input
3.2 (Low)
adjustment
The chart below shows the minimum
number of 100-pound tanks needed to
run the heater. Connect tanks together
with a manifold. Do not operate this
product with any tank smaller than 100
pounds.
Less gas is vaporized at lower tempera-
tures. Two or more 100-pound tanks or
one larger tank may be needed in colder
weather. Your local propane gas dealer will
help you select the proper supply system.
