The ‘SteamVac’ cleaner
has three agitator
brush settings:
Power Scrub - for
normal cleaning of
carpet.
Gentle Scrub - for
gentle cleaning of
carpet
Spill Pick Up - when
brushing is not desired
(such as when picking up liquid
spills).
Slide selector button (D) to the desired setting
before cleaning.
Remove clear cover
and wipe off screen
(G) with a damp cloth.
Snap cover back into
position.
Automatic Shut-Off
Agitator Speed Selector
Cleaning Indicator Screen
Brush Indicator
Transport
2.4
2.7
2.9
2.8
2.6 2.5
When the recovery tank (lower tank) is full, the
automatic “shut-off” mechanism will shut off
the cleaner suction.
When this happens, the red float disk (C) will rise
to the top of the recovery tank lid (see
illustration). The cleaner will no longer pick up
dirty solution and the motor sound will become
noticeably higher in pitch.
When this happens, turn cleaner off and empty
recovery tank before continuing use.
Check clean solution tank also; it may need to be
refilled.
The brush indicator will spin (E) when the cleaner
is turned on and the brushes are rotating.
If the indicator does not spin (F) and the pattern is
visible when the cleaner is turned on, the brushes
are not rotating.
There are two reasons why the brushes may not
be rotating:
1. Brush speed selector is turned to Spill Pick Up
(see previous section)
2. Brush indicator screen is dirty
The cleaner may
also be lifted by
placing a hand
under the upper
clean solution tank
handle as shown.
Turn cleaner off
before transporting.
To move the cleaner
from room to room,
put handle in
upright and locked
position, tilt cleaner
back on wheels, and
push forward.
7
WARNING
- To reduce the risk of electric
shock - Unplug before cleaning or servicing.
C
D
E F
G
C
D
E F
G
